Page 14 - Dicar Product Catalog - 2022

Doctor Blade Section 2a

UHMW –Ultra High Molecular Polyethylene

Ideal for metering and containing ink.
Smooth wear, no hot spots or sharp edges.

Supplied in 100 ft. rolls unless otherwise indicated.

DICAR PART THICKNESS WIDTH BEVEL OEM NOTES
Ward Veri-
DB-RSBV 0.080 1.500 45 Degree Bevel Graphics 50' Length
DB-RSBV2 0.080 2.000 45 Degree Bevel United (10) - 10' lengths
DBRS.090X1.57BV 0.090 1.570 45 Degree Bevel
DB-RS.094 0.094 1.500 Non-Bevel CCI / Haire
DB-RS.094X1.37 0.094 1.370 Non-Bevel CCI/ Haire
DB-RS2.5 0.100 2.500 Non-Bevel
DB-RS.125 0.125 1.500 Non-Bevel
DB-RS.125BV 0.125 1.500 45 Degree Bevel
DB-BV.125X2 0.125 2.000 45 Degree Bevel
DB-RSSS-A 0.006 1.250 45 Degree Bevel
DB-RSSS-B 0.006 1.375 45 Degree Bevel
DB-RSSS-C 0.008 1.250 45 Degree Bevel
DB-RSSS-D 0.008 1.375 45 Degree Bevel

DICAR GRAPHITE DOCTOR THICKNESS WIDTH BEVEL OEM NOTES
BLADES Ward
0.025 1.500 40 Degree Bevel 2317267228106 (10) - 10' lengths
DICAR PART 0.025 1.500 40 Degree Bevel Ward #19546 (10) - 125" lengths

DB-RSGR-A
DB-RSGR-L
